DMX Made Easy with the Betopper LB150: A Beginner-Friendly Guide to Pro Lighting

Learn how to use a DMX controller with the Betopper LB150 moving head light. A simple DMX lighting tutorial for DJs, stage techs, and beginners.

1. What Is DMX and Why Should You Care?

DMX512 (short for Digital Multiplex) is the universal language for lighting control. It allows one controller to manage multiple lights and effects simultaneously — from brightness and color to movement, strobe, and gobos. If you're serious about creating pro-level lighting shows, DMX is a must-have skill.

2. What You Need to Get Started

To control the LB150 via DMX, you’ll need:

• A DMX controller (hardware console or software like Wolfmix, Daslight, etc.)
• DMX signal cables (3-pin XLR)
• One or more Betopper LB150 lights
• (Optional) A DMX terminator if using long cable runs

3. How to Set Up Your LB150 with a DMX Controller

Step-by-step connection:

• Connect your controller’s DMX OUT to the LB150’s DMX IN port using a 3-pin XLR cable.
• If using multiple lights, daisy-chain from DMX OUT → DMX IN on the next fixture.
• Set each fixture to a unique DMX starting address (e.g., 001, 021, 041 depending on mode).
• Make sure your LB150 is in DMX mode, not Auto or Sound mode.

🔧 Tip: Start with 11-channel mode — it’s simpler and perfect for beginners.

4. LB150 DMX Channel Breakdown (11CH Mode)

Channel	Function	Description
CH1	Pan	Left–right head movement
CH2	Pan Fine	Precise pan adjustment
CH3	Tilt	Up–down head movement
CH4	Tilt Fine	Precise tilt adjustment
CH5	Dimmer	Controls overall brightness
CH6	Strobe	Flashing/strobe effects
CH7	Color Wheel	Switch between built-in colors
CH8	Gobo Wheel	Switch between patterns/gobos
CH9	Gobo Shake	Adds dynamic motion to gobos
CH10	Prism Control	Enables and rotates the prism
CH11	Reset	Quick reset to default position

5. Try These Effects Right Away

Here are a few quick DMX tricks to test:

• Pan & Tilt movement – CH1 + CH3
• Color change – CH7
• Gobo + Prism effect – CH8 + CH10
• Strobe flash – CH6
• Smooth dimming – CH5

You’ll instantly see how much control DMX gives you!

6. Common Troubleshooting

Q: The LB150 isn’t responding to my controller. What now?

A: Check these:

• Is the DMX cable connected properly?
• Did you assign the correct DMX address?
• Is the LB150 in DMX mode?
• Are your controller’s channel settings matching the light?

Q: Can I control multiple LB150s together?

A: Yes! Set all fixtures to the same DMX address to sync, or use different addresses to control them independently.

Start Your DMX Journey with Betopper LB150

The Betopper LB150 is an excellent fixture to begin your DMX journey — compact, powerful, and easy to control. Mastering DMX with the LB150 unlocks professional-level lighting capabilities that will elevate your performances and events.
