7R Beam 230W Sharpy Beam Light | User Manual Download |
Description
Betopper Professional Stage lighting Equipment sharpy light moving head lights Spotlight Beam 230 Touch Screen Osram 7R Lens Auto Sound Activated DMX lighting Master-Slave DJ Strobe Effects Projector.
Specification
- Power supply:100-240V AC/ 50-60HZ
- Source OSRAM 230W 7R
- color temperature:8000K
- Rated power: 500W
- Average life span: 2000H
- Movement Range: X axis:540°, Y axis:270°
- Scanning speed:5s( X-axis)/3s (Y axis)
- Beam angle:8°( X-axis)/ (Y axis) Parallel Beam Angle:0-3.8°
- Color:14 color +Blank Pattern:17+Blank
- Prism:8 prism and 16 prisms optional.
- lens: High-precision optical lens
- Dimmer:0-100% linear dimmer
- Strobe: 1-12 times/s double strobe
- Control Mode: Sound/Auto/DMX512/ Master-Slave
- Channel:16/20
Function:
1. Touch Screen
2. Speed Adjustment.
3. Macro functions: Reset/lamp on or off can be controlled by the controller.
4. lamp usage time display
5. Thermal shutdown circuit
6. Overcurrent protection circuit
7. Input signal isolating protection.
8. With the auto-correction function
Package includes:
1 x Power cable
1 x handle
1 x English User Manual
Worry-Free Warranty
Betopper always specializes in stage lighting products & Solutions with the best price, and we believe in our products, 12 months guarantee, and provide friendly easy-to-reach support.
Photometric Diagram

Gobos & Colours


Exterior Dimensions
